System - Mouse Wheel Configuration
Created: July 07, 2022 | Updated: July 07, 2022
| Applies to version: 21
This document is no longer available beyond version 21. Information can now be found here: System - Mouse Wheel Configuration Preferences for version 24
The System - Mouse Wheel Configuration page of the Preferences dialog
Summary
The System - Mouse Wheel Configuration page of the Preferences dialog is used to configure how the mouse wheel functions. You can configure the mouse wheel functioning for all editors or specifically for PCB and/or schematic documents.
Access
The dialog is accessed by clicking Mouse Wheel Configuration under the System folder in the main Preferences dialog (accessed by clicking the
button in the top right corner of the workspace).
Options/Controls
Mouse Wheel Configuration
- Action - a list of actions for which the mouse wheel can be configured. These configurations are for a mouse that has a wheel between two mouse buttons. As noted in the grid, Launch Board Insight, Change Layer and Zoom Insight Lens are configurations that affect the mouse wheel only in the PCB Editor; Change Channel affects the mouse wheel only in the schematic.
- Button Configuration - use these options to configure any keyboard button combination (Ctrl and/or Shift and/or Alt) that is required to be used along with the mouse wheel function (as listed in the grid) to perform that action.
